Pinpoint Test DK: Accelerator Pedal Position (APP) Sensor: Introduction: Notes

WARNING: This page does not describe the selected car, but rather 25 other vehicles, including the 2013 Lincoln Navigator, 2013 Lincoln MKZ, 2013 Lincoln MKX, 2013 Lincoln MKT, and 2013 Lincoln MKS. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: After clearing an APP sensor diagnostic trouble code (DTC) to verify a repair or an intermittent concern, apply the accelerator pedal before carrying out the self-test. Take 10 seconds to carry out a full sweep of the accelerator pedal from fully released to fully applied and back to fully released.

This pinpoint test is intended to diagnose the following:

APP sensor (9F836)
harness circuits: APP1, APP2, APPRTN1, APPRTN2, APPVREF1, APPVREF2, VPWR and GND
powertrain control module (PCM) (12A650)

Fig 1: Identifying Accelerator Pedal Position (APP) Sensor Connector
Courtesy of FORD MOTOR CO.

Fig 2: Identifying Instrument Panel Cluster (IPC) Connector

Courtesy of FORD MOTOR CO.
