Tire Pressure Monitor (TPM) Module: Notes
WARNING: This page is about a different car, the 2012 Ford Pickup. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of FORD MOTOR CO.
| Item |
Part Number |
Description |
| 1 |
19A435 |
TPMS module mounting bracket |
| 2 |
W707628 |
TPMS screw (1 required) |
| 3 |
15K602 |
Tire Pressure Monitoring System (TPMS) module |
| 4 |
- |
TPMS module electrical connector (part of 14401) |
| 5 |
- |
External antenna coax connector |
