Safety Belt Retractor and Pretensioner - Front, SuperCab: Notes
WARNING: This page is about a different car, the 2012 Ford Pickup, 2012 Ford F550 Super Duty, 2012 Ford F450 Super Duty, and 2012 Ford Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
RH shown in illustration, LH similar.
Fig 1: Exploded View Of Safety Belt Retractor And Pretensioner With Torque Specifications - Front, SuperCab
| Item | Part Number | Description |
|---|---|---|
| 1 | - | D-ring bolt (part of 611B08 RH/ 611B09 LH) |
| 2 | 25508 RH/ 25509 LH | Rear door upper trim panel |
| 3 | 253A36 RH/ 253A37 LH | Rear door weather-strip |
| 4 | N808453 | Rear door lower trim panel screws (3 required) |
| 5 | N807673 | Rear door lower trim panel screw |
| 6 | 60262 | D-ring cover |
| 7 | 60220 | Safety belt finish trim panel |
| 8 | - | Rear door window latch screws |
| 9 | - | Safety belt retractor and pretensioner bolt (part of 611B08 RH/ 611B09 LH) |
| 10 | 27406 RH/ 27407 LH | Rear door lower trim panel |
| 11 | - | Safety belt retractor and pretensioner belt anchor cover (part of 611B08 RH/ 611B09 LH) |
| 12 | - | Safety belt retractor and pretensioner anchor bolt (part of 611B08 RH/ 611B09 LH) |
| 13 | - | Felt washer (part of 611B08 RH/ 611B09 LH) |
