Bucket Seat with Manual Seat Track
WARNING: This page is about a different car, the 2013 Ford F-550 Super Duty, 2013 Ford F-450 Super Duty, 2013 Ford F-350 Super Duty, and 2013 Ford F-250 Super Duty. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Driver seat shown, passenger similar.
Fig 1: Front Seat Backrest Replacement Components With Torque Specifications (Bucket Seat With Manual Seat Track)
| Item | Part Number | Description |
|---|---|---|
| 1 | 62900 RH/62901 LH | Cushion cover |
| 2 | 632A22 RH/632A23 LH | Cushion foam pad |
| 3 | - | Pin-type retainer |
| 4 | 61704 RH/61705 LH | Manual seat track |
| 5 | W506841 | Cushion side shield screw |
| 6 | 61202 RH/61203 LH | Safety belt buckle |
| 7 | - | Safety belt buckle-to-seat track bolt (part of 61202/61203) |
| 8 | 61749 | Rear inboard foot cover |
| 9 | W714949 | Pin-type retainer (10 required) |
| 10 | 61749 | Front inboard foot cover |
| 11 | 14D230 | Passenger seat wire harness |
| 12 | - | Seat position sensor retainer |
| 13 | - | Seat position sensor |
| 14 | - | Manual lumbar adjuster (if equipped) (part of 65500) |
| 15 | W713066 | Rivets (if equipped) (2 required) |
| 16 | W710752 | Scrivet |
| 17 | 62186 RH/62187 LH | Cushion side shield |
| 18 | W790163 | Recline handle retaining clip |
| 19 | 61199 | Recline handle |
| 20 | 63258 RH/63259 LH | Cushion side shield insert |
| 21 | - | Lumbar handle retaining clip (if equipped) (part of 61199) |
| 22 | 61199 | Lumbar handle (if equipped) |
| 23 | W713899 | Cushion side shield screws |
| 24 | W713010 | Cushion side shield clips |
| 25 | W711045 | Cushion side shield clip |
| 26 | 62187 | Outboard foot cover |
