Liftgate/Trunk Module (LTM): Removal

WARNING: This page is about a different car, the 2013 Ford Explorer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the LH rear door tread plate.
  2. Remove the liftgate opening weather strip.
  3. Remove the liftgate opening tread plate.
  4. Remove the 2 LH cargo net anchors and position aside the LH quarter trim panel.
    G07429152
  5. Disconnect the LTM  electrical connectors and remove the pin-type retainer.
    G07429153
  6. Release the upper and lower retaining clips and remove the LTM  .
