Valve Seals: Removal

WARNING: This page is about a different variant/trim than selected.
NOTE: During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces, that enters the oil passages, coolant passages or the oil pan can cause engine failure.
  1. Remove the valve spring. REFER to Valve Springs .
  2. Remove and discard the valve seal.
    1. Position 303-468  (T94P-6510-AH) and 307-005  (T59L-100-B) over the seal.
    2. Pull up on 307-005  (T59L-100-B) and 303-468  (T94P-6510-AH) and remove the seal.
    Fig 1: Removing Valve Spring Using Valve Stem Oil Seal Remover And Slide Hammer
    G08028647Courtesy of FORD MOTOR CO.
