Crew Cab 40 Percent of 60/40 Bench Seat
WARNING: This page is about a different car, the 2013 Ford F-550 Super Duty, 2013 Ford F-450 Super Duty, 2013 Ford F-350 Super Duty, and 2013 Ford F-250 Super Duty. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Rear Seat Backrest Replacement Components With Torque Specifications (Crew Cab 40 Percent Of 60/40 Bench Seat)
| Item | Part Number | Description |
|---|---|---|
| 1 | 611A08 | Head restraint pad and frame |
| 2 | 501A04 | Head restraint trim cover |
| 3 | 610A18 | Head restraint guide (2 required) |
| 4 | 66600/66800 | Backrest trim cover/backrest foam pad |
| 5 | 63804/63840 | Cushion trim cover/cushion foam pad |
| 6 | 613A38 | Backrest frame |
| 7 | 61346 | Side shield |
| 8 | 600A58 | Screw |
| 9 | 638A74 | Side latch shield |
| 10 | 600A58 | Screw |
| 11 | 61736 | Cushion release handle |
| 12 | 600A58 | Outboard back latch-to-riser bolts |
| 13 | 600A58 | Outboard cushion latch-to-cushion bolt |
| 14 | N806910 | Outboard cushion latch lower mount bolts |
| 15 | 60692 | RH seat riser |
| 16 | 613E34 | Backrest latch handle |
| 17 | N804266 | Backrest latch-to-backrest frame bolts |
| 18 | 613D60 | RH backrest latch |
| 19 | 600A58 | Outboard cushion latch-to-cushion bolt |
| 20 | 61382 | RH cushion latch |
| 21 | 63160 | Cushion frame |
| 22 | 600A58 | Center support inner bolts |
| 23 | 60394 | Bushing |
| 24 | 60514 | Center support |
| 25 | 60394 | Bushing |
| 26 | 60692 | Center seat riser |
| 27 | 613D60 | Center backrest latch |
| 28 | 061B44 | Hook assembly |
