20 Percent Seat Backrest
WARNING: This page is about a different car, the 2013 Ford F-550 Super Duty, 2013 Ford F-450 Super Duty, 2013 Ford F-350 Super Duty, and 2013 Ford F-250 Super Duty. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Front Seat Cushion And Related Replacement Components With Torque Specifications (20 Percent Seat Backrest)
| Item | Part Number | Description |
|---|---|---|
| 1 | 64416 | Backrest cover |
| 2 | 610A18 | Head restraint guide sleeves (2 required) |
| 3 | 611A08/610A62 | Head restraint/head restraint cover |
| 4 | 64810 | Backrest foam pad |
| 5 | 61018 | Backrest frame |
| 6 | W790254 | Screws (2 required) |
| 7 | 601B30 | Safety belt bezel |
| 8 | 611B64 | Safety belt retractor |
| 9 | W715031 | Latch-to-backrest frame bolts (2 required) |
| 10 | 645A04 | Latch |
| 11 | W505274 | Latch-to-support assembly bolts (3 required) |
| 12 | W505274 | Safety belt retractor bolt |
| 13 | W707769 | Backrest pivot bolt |
| 14 | W303546 | Backrest stop bolt |
| 15 | 63388 | Rear trim panel |
| 16 | W707211 | Pin-type retainers (2 required) |
