Battery Cables - 3.5L GTDI: Removal

WARNING: This page is about a different car, the 2013 Ford Explorer. However, it is still accessible from the selected car via links, so may be relevant.

WARNING: Before beginning any service procedure, refer to SAFETY WARNINGS . Failure to follow this instruction may result in serious personal injury.

NOTE: Loosen the nut, do not remove.

Torque:
- 9 Nm (80 lb-in).
Torque:
- 9 Nm (80 lb-in).
Torque:
- 9 Nm (80 lb-in).
Torque:
- 9 Nm (80 lb-in).

Torque:

12 Nm (106 lb-in).

Torque:
- 8 Nm (71 lb-in).

Torque:

17 Nm (150 lb-in).

Torque:
- 12 Nm (106 lb-in).
Torque:
- 5 Nm (44 lb-in).

Torque:

15 Nm (133 lb-in).

Torque:

10 Nm (89 lb-in).
