Section 210 (OEM Wiring Diagrams)
>>
Turn Signal/Stop/Hazard Lamps
>>
With Hid
With Hid
WARNING:
This page is about a different car, the 2013 Ford Mustang. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Turn Signal/Stop/Hazard Lamps - Wiring Diagram (With HID)
Courtesy of FORD MOTOR CO.
