Lower Intake Manifold (View 2 of 3)
WARNING: This page is about a different car, the 2013 Ford Mustang. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of FORD MOTOR CO.
| Item |
Part Number |
Description |
| 1 |
W714841 |
Thermostat housing bolt (4 required) |
| 2 |
8592 |
Thermostat housing |
| 3 |
8A571 |
Thermostat housing gasket |
| 4 |
9A425 |
Thermostat housing-to-coolant tube O-ring seal |
| 5 |
18472 |
Heater hose-to-lower intake manifold |
