Lower Intake Manifold (View 1 of 3)
WARNING: This page is about a different car, the 2013 Ford Mustang. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of FORD MOTOR CO.
| Item |
Part Number |
Description |
| 1 |
- |
Fuel tube-to-fuel rail quick connect coupling (part of 9J280) |
| 2 |
6P013 |
LH fuel rail noise insulator shield |
| 3 |
6P013 |
RH fuel rail noise insulator shield |
| 4 |
- |
Fuel injector electrical connector (part of 12C508) (6 required) |
