Cylinder Head (View 1 of 2)

Fig 1: Exploded View Of Cylinder Head (View 1 Of 2) With Torque Specifications

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	W705443	Flexpipe-to-muffler and tailpipe assembly nut (2 required)
2	5G232	Flexpipe
3	9451	Flexpipe-to-muffler and tailpipe assembly gasket
4	W710512	Catalytic converter-to-engine support bracket bolt (2 required)
5	-	Catalytic converter support bracket bolt (part of 5K222) (2 required)
6	5K222	Catalytic converter support bracket
7	-	Catalytic converter heat shield bolt (part of 5K282) (4 required)
8	W503922	Catalytic converter heat shield bolt (2 required)
9	5K282	Catalytic converter heat shield
10	14A624	Heated Oxygen Sensor (HO2S) electrical connector (part of 12A690)
11	14A624	Catalyst Monitor Sensor (CMS) electrical connector (part of 12A690)
12	W703933	Catalytic converter nut (7 required)
13	5G232	Catalytic converter
14	9448	Catalytic converter gasket
15	W704474	Catalytic converter-to-cylinder head stud (7 required)
