Removal and Installation

WARNING: This page is about a different variant/trim than selected.
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to JACKING & LIFTING article.
  2. Remove the 5 bolts, pin-type retainer (not shown in illustration) and the RH splash shield.
    • To install, tighten to 9 Nm (80 lb-in).
    Fig 1: Locating RH Splash Shield Bolts
    G07439305Courtesy of FORD MOTOR CO.
  3. Disconnect the Engine Oil Pressure (EOP) switch electrical connector.
  4. Remove the EOP  switch.
    • To install, tighten to 15 Nm (133 lb-in).
  5. To install, reverse the removal procedure.
