Oil Pan, Oil Pump Screen and Pickup Tube, Front Wheel Drive (FWD) Vehicles

WARNING: This page is about a different variant/trim than selected.
NOTE: Automatic transmission shown in illustration, manual transmission similar.
Fig 1: Exploded View Of Engine Lubrication Components With Torque Specifications - (2 Of 5)
G07439300Courtesy of FORD MOTOR CO.
PARTS DESCRIPTION CHART

Item Part Number Description
1 W500121 Upper bellhousing-to-engine bolts
2 W500121 LH bellhousing-to-engine bolt
3 W500125 LH bellhousing-to-engine bolt
