Oil Pan, Oil Pump Screen and Pickup Tube, All-Wheel Drive (AWD) Vehicles

Fig 1: Exploded View Of Engine Lubrication Components With Torque Specifications - (3 Of 5)

Courtesy of FORD MOTOR CO.

PARTS DESCRIPTION CHART

Item	Part Number	Description
1	W500125	RH engine-to-bellhousing bolts (2 required for automatic transaxle) (1 required for manual transaxle)
2	W707386	RH engine bracket-to-Power Transfer Unit (PTU) bolts
