LH Cylinder Head
WARNING: This page is about a different variant/trim than selected.
ITEM DESCRIPTION
| Item | Part Number | Description |
|---|---|---|
| 1 | 6065 | Cylinder head bolt (8 required) |
| 2 | 6529 | Camshaft roller follower (12 required) |
| 3 | 6C501 | Hydraulic lash adjuster (12 required) |
| 4 | 6050 | Cylinder head |
| 5 | 6750 | Oil level indicator |
| 6 | 6754 | Oil level indicator tube |
| 7 | W701822 | Oil level indicator tube stud bolt |
| 8 | 110282 | Oil level indicator tube O-ring |
| 9 | 6083 | Cylinder head gasket |
