Direct (3, 5, R) Clutch Exploded View
WARNING: This page is about a different variant/trim than selected.
ITEM DESCRIPTION CHART
| Item | Part Number | Description |
|---|---|---|
| 1 | 7C122 | Direct clutch cylinder snap ring |
| 2 | 7F283 | Direct clutch cylinder |
| 3 | 7A262 | Direct clutch piston |
| 4 | 7F235 | Direct clutch piston return spring |
| 5 | 7C099 | Direct clutch piston seals |
| 6 | 7G384 | Direct/Overdrive (O/D) clutch hub |
| 7 | 7F213 | Input shaft |
| 8 | 7B070 | Direct clutch wave spring |
| 9 | 7B164 | Direct (3, 5, R) clutch assembly |
| 10 | 7B066 | Direct clutch pressure plate |
| 11 | 7D483 | Direct clutch snap ring |
| 12 | 7A019 | Rear planetary sun gear and shell assembly |
