Daytime Running Lamps

Fig 1: Daytime Running Lamps Schematic (1 Of 2)

G07855399

Courtesy of FORD MOTOR CO.

Fig 2: Daytime Running Lamps Schematic (2 Of 2)

G07855400

Courtesy of FORD MOTOR CO.
