Sliding Glass, Blinds and Primary Seal
NOTE:
LH side shown in illustration, RH side similar.
PARTS DESCRIPTION CHART
| Item | Part Number | Description |
|---|---|---|
| 1 | 500A66 LH/500A67 RH | Concertina blinds (2 required) |
| 2 | W790079 | Roof opening panel front glass screws (4 required) |
| 3 | W790078 | Roof opening panel rear glass screws (2 required) |
| 4 | 51884 | Roof opening panel primary glass seal |
| 5 | 18500A18 | Roof opening sliding glass panel |
