Inboard Side of Cushion Frame and Power Seat Track From Underneath

Fig 1: Identifying Cushion Frame And Power Seat Track Components Location
G07403117Courtesy of FORD MOTOR CO.
ITEM DESCRIPTION CHART

Item Description
1 Front inboard Occupant Classification System (OCS) weight sensor bolt electrical connector
2 Attaches to inboard OCS  weight sensor bolt protection bracket
3 Rear inboard OCS  weight sensor bolt electrical connector
