Heated Seat Switch - Rear

Heated Seat Switch - Rear









Removal and Installation

1. NOTICE: The heated seat switch wiring harnesses are very short. Be careful not to damage the switch, connector or wiring when detaching the rear panel from the console.

Remove the rear panel from the front floor console.

- Detach the 6 retainer clips.

- Disconnect the LH and RH heated seat switch electrical connectors.

- If equipped, disconnect the power point electrical connector.

2. Detach and remove the heated seat switch(s).

3. To install, reverse the removal procedure.
