Pinpoint Test JB: Secondary Ignition (COP): Introduction
WARNING: This page does not describe the selected car, but rather 30 other vehicles, including the 2010 Mercury Milan, 2010 Mercury Mariner, 2010 Mercury Grand Marquis, 2010 Lincoln Town Car, and 2010 Lincoln Navigator L. However, it is still accessible from the selected car via links, so may be relevant.
A damaged ignition system may cause high catalyst temperatures. Check the components next to the catalyst and muffler for heat damage.
This pinpoint test is intended to diagnose the following:
- spark plugs (12405)
- secondary side of the coil
CYLINDER APPLICATIONS CHART
| Vehicle | Firing Order for Coil On Plug Applications |
|---|---|
| BASE, 4-cylinder applications | 1 3 4 2 |
| BASE, 6-cylinder applications | 1 4 2 5 3 6 |
| BASE, 8-cylinder applications | 1 3 7 2 6 5 4 8 |
| BASE, 10-cylinder applications | 1 6 5 10 2 7 3 8 4 9 |
