Thermostat Housing: Material
WARNING: This page is about a different car, the 2010 Lincoln MKX and 2010 Ford Edge. However, it is still accessible from the selected car via links, so may be relevant.
MATERIAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Motorcraft® Specialty Green Engine Coolant VC-10-A2 (US); CVC-10-A (Canada) |
WSS-M97B55-A |
PARTS DESCRIPTION CHART
| Item | Part Number | Description |
|---|---|---|
| 1 | 8W005 | Vent hose |
| 2 | 8B273 | Lower radiator hose |
| 3 | 8B274 | Upper radiator hose |
| 4 | 18K580 | Heater core outlet hose |
| 5 | 18K579 | Heater core inlet hose |
| 6 | W503279 | Thermostat housing bolt (3 required) |
| 7 | 8565 | O-ring seal |
| 8 | 8A571 | O-ring seal |
| 9 | 8A587 | Thermostat housing |
