Removal and Installation

WARNING: This page is about a different car, the 2010 Lincoln MKX and 2010 Ford Edge. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the hood latch. For additional information, refer to HOOD LATCH .
  2. Disconnect the hood latch release cable locator from the radiator grille opening panel reinforcement.
  3. Disconnect the hood latch release cable locator from the LH inner fender.
    4. NOTE: The hood latch release handle and cable assembly must be pulled through the dash panel into the passenger compartment.
  4. Remove the hood latch release handle and cable assembly.
    1. Remove the hood latch release handle screw.
    2. Remove the hood latch release handle and cable assembly.
      Fig 1: Identifying Hood Latch Release Handle And Cable Assembly
      G06506049Courtesy of FORD MOTOR CO.
  5. To install, reverse the removal procedure.
