Front of Cushion Frame and Power Seat Track From Underneath
WARNING: This page is about a different car, the 2010 Lincoln MKX and 2010 Ford Edge. However, it is still accessible from the selected car via links, so may be relevant.
ITEM DESCRIPTION CHART
| Item | Description |
|---|---|
| 1 | Seat control switch and rear height motor takeout must be routed on top of the bracket |
| 2 | Wire harness attachment points |
| 3 | Horizontal motor electrical connector |
| 4 | Safety belt buckle switch electrical connector pin-type retainer attached in place |
