Stator Support and Gear Assembly: Assembly

WARNING: This page is about a different car, the 2010 Lincoln MKX and 2010 Ford Edge. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the Support Solid Seal Installer 307-579/3 on the stator support assembly.
    Fig 1: Installing Support Solid Seal Installer 307-579/3
    G06076300Courtesy of FORD MOTOR CO.
  2. Install a new seal on the Support Solid Seal Installer 307-579/3.
    Fig 2: Installing Seal On Support Solid Seal Installer 307-579/3
    G06068456Courtesy of FORD MOTOR CO.
  3. Install the Support Solid Seal Installer 307-579/2 on the Support Solid Seal Installer 307-579/3 and slide the seal in to the groove on the stator support assembly.
    Fig 3: Installing Support Solid Seal Installer 307-579/2 On Support Solid Seal Installer 307-579/3
    G06076302Courtesy of FORD MOTOR CO.
  4. Remove the Support Solid Seal Installer 307-579 (includes 307-579/2 and 307-579/3) from the stator support assembly.
    Fig 4: Removing Support Solid Seal Installer 307-579
    G06068458Courtesy of FORD MOTOR CO.
  5. Install the Support Solid Seal Installer 307-579/1 on the stator support assembly to size the seal.
    Fig 5: Locating Support Solid Seal Installer 307-579/1 On Stator Support Assembly
    G06076304Courtesy of FORD MOTOR CO.
  6. Install a new gasket on the stator support assembly.
    Fig 6: Locating Stator Support Assembly
    G06076305Courtesy of FORD MOTOR CO.
  7. Position the stator support feed tube assembly in place and install the bolts hand-tight  .
    Fig 7: Locating Stator Support Feed Tube Assembly
    G06076306Courtesy of FORD MOTOR CO.
  8. Tighten the 2 stator support feed tube Torx head bolts.
    • Tighten to 7 Nm (62 lb-in).
      Fig 8: Tightening Stator Support Feed Tube Torx Head Bolts
      G06068462Courtesy of FORD MOTOR CO.
  9. Tighten the 2 stator support feed tube hex-head bolts.
    • Tighten to 12 Nm (106 lb-in).
      Fig 9: Tightening Stator Support Feed Tube Hex-Head Bolts
      G06068463Courtesy of FORD MOTOR CO.
  10. Install a new input shaft seal on the Support Seal Installer 307-585.
    Fig 10: Installing Input Shaft Seal On Support Seal Installer 307-585
    G06068464Courtesy of FORD MOTOR CO.
  11. Using the Support Seal Installer 307-585, install the input shaft seal.
    Fig 11: Installing Input Shaft Seal Using Support Seal Installer 307-585
    G06076310Courtesy of FORD MOTOR CO.
  12. Remove the Support Seal Installer 307-579/1 from the stator support assembly.
    Fig 12: Removing Support Seal Installer 307-579/1 From Stator Support Assembly
    G06076311Courtesy of FORD MOTOR CO.
  13. Install the drive sprocket thrust washer.
    Fig 13: Installing Drive Sprocket Thrust Washer
    G06068467Courtesy of FORD MOTOR CO.
  14. Install a new stator support assembly seal.
    Fig 14: Installing Stator Support Assembly Seal
    G06068468Courtesy of FORD MOTOR CO.
