Liftgate Handle, Lock and Latch - Exploded View
WARNING: This page is about a different car, the 2009 Mercury Sable, 2009 Ford Taurus X, and 2009 Ford Taurus. However, it is still accessible from the selected car via links, so may be relevant.
| Item | Part Number | Description |
|---|---|---|
| 1 | 14018 | Liftgate latch release switch |
| 2 | 74402A30 | Liftgate molding |
| 3 | W709764 | Liftgate molding nuts (4 required) |
| 4 | 7483150 | Liftgate latch |
| 5 | W505426 | Liftgate latch bolts (3 required) |
- For additional information, refer to the appropriate procedures.
