Door Disarm Switch: Notes
WARNING: This page is about a different car, the 2009 Mercury Grand Marquis and 2009 Ford Crown Victoria. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of FORD MOTOR CO.
| Item |
Part Number |
Description |
| 1 |
22135 |
Door lock cylinder actuating rod |
| 2 |
- |
E-clip |
| 3 |
- |
Door lock cylinder actuating pawl |
| 4 |
220A40 |
Door disarm switch |
| 5 |
- |
Door disarm switch electrical connector (part of 220A40) |
