Fuel Pump Driver Module (FPDM): Notes
WARNING: This page is about a different car, the 2009 Ford Mustang. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of FORD MOTOR CO.
| Item |
Part Number |
Description |
| 1 |
14A464 |
RH fuel pump driver module (FPDM) electrical connector (part of 14A005) |
| 2 |
W504755 |
RH FPDM bolt (2 required) |
| 3 |
9D370 |
RH FPDM |
| 4 |
14A464 |
LH FPDM electrical connector (part of 14A005) |
| 5 |
W504755 |
LH FPDM bolt (2 required) |
| 6 |
9D370 |
LH FPDM |
