Power Steering Pump Pulley - 4.6L, 5.4L: Notes

WARNING: This page is about a different car, the 2009 Ford Mustang. However, it is still accessible from the selected car via links, so may be relevant.

Special Tools

Illustration	Tool Name	Tool Number
Courtesy of FORD MOTOR CO.	Installer, Power Steering Pump Pulley	211-185 (T91P-3A733-A)
Courtesy of FORD MOTOR CO.	Remover, Power Steering Pump Pulley	211-016 (T69L-10300-B)

Fig 1: Exploded View Of Power Steering Pump Pulley - 4.6L Engine

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	8620	Accessory drive belt
2	3A733	Power steering pump pulley
3	3A674	Power steering pump

Fig 2: Exploded View Of Power Steering Pump Pulley - 5.4L Engine

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	3A674	Power steering pump
2	8620	Accessory drive belt
3	3A733	Power steering pump pulley
