Pinpoint Test KP: Charge Air Cooler (CAC) Pump: Introduction
This pinpoint test is intended to diagnose the following:
- CAC pump relay (14B192)
- CAC pump (8501)
- harness circuits: CAC, VPWR and GND
- powertrain control module (PCM) (12A650)
Courtesy of FORD MOTOR CO.
Courtesy of FORD MOTOR CO. POWERTRAIN CONTROL MODULE (PCM) CONNECTOR
| Pin |
Circuit |
| E64 |
CAC (Charge Air Cooler) |
