Hood Latch: Notes

NOTE: Radiator grille shown in illustration removed for clarity.

Fig 1: Locating Outer Safety Belt Trim Guide With Torque Specifications

Courtesy of FORD MOTOR CO.

WINDOW GLASS - ROOF

Item	Part Number	Description
1	N808727	Hood latch bolts (2 required)
2	16700	Hood latch
3	16916	Hood latch release cable
4	N807658	Hood latch striker bolts (2 required)
5	16K689	Hood latch striker
