Hood Latch Release Handle: Notes

Fig 1: Hood Latch Release Handle With Torque Specification
G06071176Courtesy of FORD MOTOR CO.
MATERIAL

Item Part Number Description
1 W505424 Hood latch release handle bolt
2 16916 Hood latch release handle and cable
