Exterior Door Handle: Notes

Fig 1: Identifying Exterior Door Handle Components
G06071183Courtesy of FORD MOTOR CO.
INSTALLATION

Item Part Number Description
1 - Exterior door handle bezel
2 7822404 Exterior door handle
3 - Exterior door handle bezel retaining screw
4 W714032 Plug
