Special Tool(s)
SPECIAL TOOL REFERENCE
| Remover, Front Wheel Hub 205-D070 (D93P-1175-B) or equivalent |
ITEM DESCRIPTION CHART
| Item | Part Number | Description |
|---|---|---|
| 1 | W712435 | Front wheel hub nut |
| 2 | W710015 | Ball joint nut |
| 3 | 3K170 | Lower control arm |
| 4 | W7 09290 | Brake hose bracket bolt |
| 5 | W520413 | Bearing support nuts |
| 6 | 3B436 | Halfshaft assembly |
