Instrument Panel Upper Section
TIGHTENING TORQUE SPECIFICATIONS
| Item | Part Number | Description |
|---|---|---|
| 1 | W505424 | Hood release handle bolt |
| 2 | 16916 | Hood release handle |
| 3 | W707628 | Instrument panel upper section screw (13 required) |
| 4 | 04320 | Instrument panel upper section |
| 5 | 04545 | In-vehicle crossbeam |
- For additional information, refer to the appropriate procedures.
