Removal and Installation

  1. Remove the instrument cluster. For additional information, refer to INSTRUMENT CLUSTER  in this article.
  2. Remove the 5 instrument cluster screws and the instrument cluster lens.
    Fig 1: Removing Instrument Cluster Lens
    G04009214Courtesy of FORD MOTOR CO.
  3. To install, reverse the removal procedure.
