Water Pump - 2.3L: Material

WARNING: This page is about a different variant/trim than selected.
MATERIALS

Item Specification
Motorcraft Premium Gold Engine Coolant VC-7-A (in California, Oregon and New Mexico VC-7-B, in Canada CVC-7-A) or equivalent (yellow color) WSS-M97B51-A1
Fig 1: Exploded View Of Water Pump - 2.3L With Torque Specifications
G03900341Courtesy of FORD MOTOR CO.
