Instrument Cluster - Expedition

Fig 1: Identifying Instrument Cluster - Expedition
G02780076Courtesy of FORD MOTOR CO.

The Navigator instrument cluster consists of the following gauges and indicators:

NOTE: The English cluster is shown, the metric cluster is similar.
