Pinpoint Test G: The Front Fog Lamp Switch Illumination Is Inoperative (If Equipped)

Fig 1: Pinpoint Test G: Disassembling Front Fog Lamp Switch Illumination Is Inoperative (If Equipped)
G02742588Courtesy of FORD MOTOR CO.
