Removal and Installation

  1. Remove the instrument cluster. For additional information, refer to INSTRUMENT CLUSTER .
  2. Remove the necessary instrument cluster bulbs by rotating the bulb one quarter turn counterclockwise and lifting straight out of the instrument cluster.
    Fig 1: Removing/Installing Instrument Cluster Bulb
    G01628224Courtesy of FORD MOTOR CO.
  3. To install, reverse the removal procedure.
