Pinpoint Test U: The Stoplamps Are On Continuously - High Mounted Stoplamp Only

NOTE: The ignition switch must be cycled from OFF to RUN to enable the SSP feature.
Fig 1: Pinpoint Test U: Stoplamps Are On Continuously - High Mounted Stoplamp Only
G03423398Courtesy of FORD MOTOR CO.
