Pinpoint Test T: The Stoplamps Are On Continuously - LR Stoplamp Only

NOTE: The ignition switch must be cycled from OFF to RUN to enable the SSP feature.
Fig 1: Pinpoint Test T: Stoplamps Are On Continuously - LR Stoplamp Only
G03423397Courtesy of FORD MOTOR CO.
