Pinpoint Test D: The Headlamps Are On Continuously - Single Low/High Beams

NOTE: The ignition switch must be cycled from OFF to RUN to enable the SSP feature.
Fig 1: Pinpoint Test D: Headlamps Are On Continuously - Single Low/High Beams (D1-D3)
G03423355Courtesy of FORD MOTOR CO.
Fig 2: Pinpoint Test D: Headlamps Are On Continuously - Single Low/High Beams (D4-D6)
G03423356Courtesy of FORD MOTOR CO.
