Pinpoint Test AO: The Reversing Lamps Are On Continuously

NOTE: The ignition switch must be cycled from OFF to RUN to enable the SSP feature.
Fig 1: Pinpoint Test AO: Reversing Lamps Are On Continuously
G03423456Courtesy of FORD MOTOR CO.
