Pinpoint Test E: One High Beam Headlamp Is Inoperative

WARNING: This page is about a different car, the 2003 Mercury Sable and 2003 Ford Taurus. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Pinpoint Test E: One High Beam Headlamp Inoperative (Step E1)
G01595093Courtesy of FORD MOTOR CO.
