Pinpoint Test A: The Control Illumination Is Inoperative

WARNING: This page is about a different car, the 2003 Mercury Sable and 2003 Ford Taurus. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Pinpoint Test A: Control Illumination Inoperative (Step A1-A3)
G01593707Courtesy of FORD MOTOR CO.
