Valve Seals: Installation

WARNING: This page is about a different car, the 2003 Mercury Sable and 2003 Ford Taurus. However, it is still accessible from the selected car via links, so may be relevant.
  1. Using the special tool, install the valve seal.
    Fig 1: Installing Valve Seal
    G01592859Courtesy of FORD MOTOR CO.
  2. Install the valve spring. For additional information, refer to VALVE SPRING .
