Oil Pan: Removal

WARNING: This page is about a different car, the 2003 Mercury Sable and 2003 Ford Taurus. However, it is still accessible from the selected car via links, so may be relevant.

Disconnect the battery ground cable. For additional information, refer to BATTERY, MOUNTING AND CABLES .
Raise and support the vehicle.
Remove the dual converter Y-pipe. For additional information, refer to EXHAUST SYSTEM .
Remove the starter motor. For additional information, refer to STARTERS .
Remove the bolt and the engine rear plate.

Fig 1: Removing Bolt And Engine Rear Plate
Courtesy of FORD MOTOR CO.
Drain the engine oil.

Fig 2: Locating Engine Oil Drain Plug
Courtesy of FORD MOTOR CO.
Remove the 16 bolts and the oil pan.

Fig 3: Removing Oil Pan
Courtesy of FORD MOTOR CO.
Remove the oil pan gasket from the oil pan.

Fig 4: Removing Oil Pan Gasket From Oil Pan
Courtesy of FORD MOTOR CO.
Using metal surface cleaner, clean the oil pan sealing surfaces.
